1. Characteristics:

1) The machine adopts double teeth rod adjusting structure, easy to operate; Quickly;

2) To glue adopts veneer operating structure, convenient and correct continuous broadcasting film, glue interval can be adjusted do promise. The folding part adopts fluctuation belt design, can make the first line and the third line 180 degrees of fold box of

3)Equipped with high quality inverter, infinitely adjustable-speed running equipment can do without

4) Self-contained side gluing device, application is very flexible and can stick in the outside. Spray adhesive department specially design;* PET material box first adopts photoelectric glue injector, glue and transparent with no white viscose parts are linear * PP plastic box of hot melt equipment with the use of new technologies, without glue, safe environmental protection;

5) Adopts photoelectric counter, feasible quantitative count. Transport department balanced indeed. To ensure the perfect quality

2. Main technical parameter:

3.Machine configuration

4.Standard & Optional configuration list

5.Feature:

1)the average speed of gluing box is 8000-10000pcs / hour, speed is very fast , greatly improve production efficiency.
2) automatic feeding, automatic glue, automatic folding, automatic calibration, automatic counting, only two people can complete the whole process.
3) the suction belt feeding way, simple structure, fast speed, paper accurately.
4) the nail tooth belt feed, feed accuracy;and it has secondary indentation function, make folding cartons more accurately.
5) with functions of secondary rectification, eliminate the size of the different mouth, reduce rejection rate.
6) with differential correction regulating function, eliminate shear knife and fork, fold more accurate.
7) receiving paperboard unit can automatic counting, shape adjusting then stacking , all carton can be piled up according to a certain quantity , then output , high speed and precision.
8) can match with the automatic strapping machine .
